• Twaron hull, a carbon aramid fiber with alternating FRP glass lay-up hand laid with no core and using vinylester resins and Isophthalic Gel-coat
• Three coats of bottom paint
• Watertight collision bulkhead forward of forward cabin
• Watertight Stern sections across aft lazarettes and stern locker
• Divided Anchor Locker with separate locker for fenders and dock lines
• Large Aft Stern lazarettes, port and starboard with dual Bailey latches for watertight seal
• Stern Garage with dedicated Rule Auto bilge pump with manual over ride in cockpit
• Very large step down sail locker with deck hatch access. 5’ deep and 4’ long
• Solid Lead Keel with solid 40mm stainless steel keel bolts with transverse mounted 13mm backing plates
• Partially skegged rudder for optimal performance, strength and protection
• Bottom of rudder plane in each model above the keel plane for grounding safety
• Solid GRP fiberglass in all areas of deck for deck fittings and stress area
• Molded contrasting nonskid available in two in linen beige or whisper gray
• Solid stainless stern head fitting with split bow roller with stowage for 110 lbs. stainless steel Ultra Anchor
• Solid Stainless striker plates for bow protection
• Salt-water washdown pump for anchor washdown
• Two pair of stainless steel 12” bow cleats, pair of 12” midship cleats and one pair of 12” stern cleats
• 32” high stanchions 1” in diameter with double lifelines
• Side Boarding ladder with port and starboard side mounting brackets
• Mainship 316 stainless overhead hatches and ports throughout
• Winch Inventory:
  Primary Winches: Hydraulic Antal XT66’s (2ea)
  Secondary Winches: Antal XT52 ‘s (2ea)
  Mainsheet Winch: Hydraulic Antal XT48 (1ea)
  Cockpit Winch: Antal XT48 (1ea)
  Halyard Winches: Antal XT48’s (2ea)
• Harken Stand up Staysail Blocks
• Teak Handrails on foredeck coach roof and aft coach roof
• Stainless steel companionway handrails
• Stainless coach roof handrails
• Hollywood pedestal with chart plotter and instruments
• Ritchie 5” Compass
• Solid Teak varnished cockpit table
• Solid stainless Cowl Vents, 4 Total. One pair forward and one pair aft
• Stainless protective stern plate

• Yanmar 4JH150 4-cylinder turbo diesel engine with cockpit controls and complete alarm system
• Morse single lever control system to protect against high RPM gear shifting
• Dual Racor fuel filtration system allowing independent filter and bypass system
• Walborough In line fuel pump allowing engine bypass for filtration and eliminates the need for future engine bleeding in the case of a dry fuel tank
• Oil change pump built in as standard
• All wire is tinned, no copper wiring except some electronics
• All thru hull fittings are solid bronze and all bonded
• Six AGM 8D House batteries, 1,350 amp/hr total, All batteries boxed and secured
• AGM Engine starting battery, 210 amp
• All batteries are isolated with a built in reverse isolation switch
• Primary High Output 130A Alternator dedicated to house bank
• Dedicated 60A Alternator for Engine Battery
• Fire retardant engine room sound insulation
• All batteries self-contained, strapped and secured
• Fire retardant engine room sound insulation
• Shore power connection; 50/amp 125/250V
• Mastervolt 100 amp built in battery charger
• Navigation lights: running lights masthead anchor; tricolor steaming light and foredeck light
• Raymarine depth sounder, speed log and wind speed indicator
• Three independent bilges pump systems
• Solid Drive steering system in lieu of chain and cable design
• Freshwater hot and cold shower on stern platform
• Stainless stern swim ladder
• Inner Forestay Chain plate for optional inner forestay

• European oak interior
• Solid teak soles laid on sub-flooring with epoxy urethane coating and 7 layers of varnish
• European oak doors and trim
• Finely finished cabinetry with a choice of solid or louvered finish
• Solid oak handrails throughout the interior for easy movement offshore
• Abundant overhead hatches and ports for excellent ventilation
• Epoxy sealed end grains and sub-flooring
• All cabin sole pieces are positive locking for offshore passage making
• All cabinets are finished throughout including complete interiors
• All overhead headliner is easily removed

• 275 Gallons of Total Fuel Tankage in four independent tanks
• 280 Gallons of Total Water Tankage in four independent tanks
• All tanks have easy access for inspection with dipsticks, threaded inspection port and larger inspection
• Port for interior inspection and cleaning
• Two independent Shurflow freshwater pump systems
• Third manual freshwater pump, foot activated for freshwater accessed in the galley
• All tankage for water and fuel is 316L stainless steel for best corrosion resistance
• Two independent holding tanks, one dedicated to each head
• 11 gallon hot water heater heated via engine driven system or AC supply
• All through hull fittings are bronze with seacocks or valves and bonded

• Galley is over 10.5’ in length with a walk through to the aft cabin offering total safety with room to brace on either tack while offshore
• Ample cabinets, storage lockers and drawers including full length pantry for cutlery, cookware, and food storage
• Slide out trash container with positive locking door
• Force 10 three burner stove with propane monitor and 2 propane sensors
• Two Vitrifrigo 180DRW two drawer refrigeration/freezer units
• Counter top recesses over stove allowing for stainless steel backsplash and increased counter space when in place
• Manual foot pumps for fresh water

• Full L shaped nav station with two desk areas and adjustable swivel chair
• Dedicated computer desk with slide out computer shelf with book shelf above
• Split instrument panel for access to wiring harness and connections
• All instruments and systems well labeled inside and out and traced numerically

• Queen size Aft Berth set centerline with split mattress and accompanying starboard side settee
• Port and Starboard side hanging lockers with optional removable shelves
• Full length deep hanging locker centerline
• Portside vanity with fold up mirror and drawer with three separate cabinets
• Cabinet or drawers available under owners berth
• Separate owners shower stall
• Washer/dryer located outboard of shower
• Raritan Elegance electric toilet
• 42 gallon dedicated holding tank with dual “Y” valve systems for direct overboard, deck pump
• Out and direct pump out of holding tank overboard

• Dinette table with inlay and folding corners to reduce table size. The table can also be lowered to coffee table height if desired.
• Full length starboard settee pulls out an additional 9” for a wide sea berth
• All tankage in main salon is located below the sole allowing extensive storage under seating areas and behind the dinette and settee
• Double walk through passageway offering optimal ventilation and movement throughout the interior
• Two folding stools become footrests or cocktail tables
• Maximum Headroom just under 7’

• Centerline Berth with Lifting Top
• Split cabinet doors or Two rows of drawers underneath berth with two separate isolated storage bins
• Starboard and portside hanging lockers with removable shelves
• Cabinets above the berth for added storage

• Separate enclosed shower stall
• Raritan Elegance electric toilet
• 39 gallon dedicated holding tank with dual “Y” valve systems for direct over board, and deck pump out of holding tank

Convertible double berth with a stainless steel workbench surface underneath the mattress, that allows the cabin to also be used as a workshop. There is a large amount of storage throughout this cabin contributing to the versatility and value of this third cabin configuration.

• Selden anodized aluminum mast with triple spreader rig
• Stainless wiring standing rigging with Sta-lock Mechanical fittings. No swage fittings at deck
• Forward and aft lowers for rig stability with individual chain plates
• Discontinuous rigging for optimal strength and increased hardware
• In mast hydraulic mainsail furling
• Furlex hydraulic roller furling forestay
• Furlex hydraulic roller furling staysail
• Doyle sails including mainsail, genoa, staysail
• Primary and secondary main halyard
• Primary and secondary genoa halyard
• Halyard bales on forward dorades

• RC12 Maxwell Nilsson windlass with chain feed and stainless steel plate for chain protection with bow controls and remoter cockpit windlass controls
• Primary anchor, 100 lbs. Stainless Steel Ultra Anchor
• Secondary anchor, Fortress Aluminum anchor
• Primary anchor and tackle: 300’ system 40-3/8” galvanized Hi tensile chain
• Secondary anchor and tackle: 50’ system 40-3/8” Hi tensile chain and 300’ of 5/8” anchor rode
• Four dock lines, 2 x 35’ x 5/8” premium braid, 2 x 40’ x 5/8” premium braid
